Specification
| Product | Medical surgical electric portable bone drill |
| Main Material | Aluminum Alloy |
| MOQ | 1set |
| Application | Orthopedic Surgical Instruments |
| Bone drill speed | 0-1300r/m |
| Cannulated drill speed | 0-600r/m |
| Oscillating saw | 0-18000osc/m |
| Acetabular bone drill | 0-300r/m |
| Craniotomy drill | 0-900r/m |
| Sternum saw | 0-15000osc/m |
| Saw non-load noise | 75dB |
| Drill non-load noise | 65dB |
| Diameter run-out | 0.5mm |
| Oscillations | 0-15000r/min |
Note: Only include one pc adapter, it uses for nm500 host.
Technical Merits
- CE, ISO & SGS Approved.
- Mainframe is made of Stainless Steel, durable, long working time, the accessories can be selected freely by different operation.
- Quick chuck: Imported chuck ensures outstanding performance during operation.
- Sternum saw: Both 360° rotating head and blade guard can protect soft tissue around sternum.
- Craniotomy mill: 40000r.p.m rates assures fast, efficient and safe process in craniotomy.
- Oscillating saw: 360° rotating head can be applied to any surgical sites. Wrenchless collet allows for easy, fast and safe loading and unloading blades.
- Reamer: Hi-torque, ideal for acetabulum or medullary operation. Available to all brands mill universal.
- Wire and pin chuck: With a cannula diameter 4.0mm applied to various intramedullary pin or kirschner pin fixing operation easily and conveniently.
- Cranial drill: Auto-pause offer perforation ensures safety in neurosurgery.
- Highest quality Surgical Instrument Multifunctional Bone Drill Saw.
- Perfect ergonomic design.
- This kind of surgical instrument can meet different kinds of surgery operation.
Packaging Options
Two choices: with aluminum box or with sterilized box, please choose before ordering.
With aluminum case
With sterilizer box
Frequently Asked Questions (FAQ)
Q: What is the main material used in the construction of this bone drill?
A: The main body of the surgical bone drill is constructed from high-quality Aluminum Alloy, ensuring durability and a long working life.
Q: Is this drill suitable for different types of surgeries?
A: Yes, this is a multifunctional surgical instrument designed to meet the requirements of various surgical operations, including orthopedic, neurosurgery, and more.
Q: What are the packaging options available?
A: We offer two packaging choices: an aluminum box or a specialized sterilized box. Please specify your preference when ordering.
Q: Does this device require specific accessories?
A: Yes, it supports various attachments (such as sternum saws, craniotomy drills, and reamers) which can be selected freely based on the specific surgical needs.
Q: Is this medical instrument certified?
A: Yes, this surgical bone drill is CE, ISO, and SGS approved, ensuring it meets international quality and safety standards.
